Specification
| Basic Information | ||
| Processor | Intel Core i7-13620H 10 Cores (6P + 4E) 16 Threads Frequency: P-core up to 4.9GHz, E-core up to 3.6GHz 24MB Intel Smart Cache |
|
| Motherboard | Chipset: Intel B760 Chipset | |
| RAM | 1x 8GB SODIMM DDR5-5200 Memory Slots: Two DDR5 SODIMM slots, Dual-channel capable Expandable Memory: Up to 32GB DDR5-5200 |
|
| Graphics Card | Integrated Intel UHD Graphics | |
| Storage | 512GB M.2 2280 PCIe 4.0×4 NVMe SSD Max Storage Support: Up to three drives, 1x 3.5″ HDD + 2x M.2 SSD • 3.5″ HDD bay only for customer self-upgrade • M.2 SSD up to 1TB each |
|
| Audio | Audio Chip: High Definition (HD) Audio, Realtek ALC623-CG codec 24-bit DAC supports 44.1K/48K/96K sample rate, 2-channel DAC supports 16/20/24-bit PCM format for independent two stereo channels or 2.1 audio playback 24-bit ADC supports 44.1K/48K/96K sample rate, 2-channel ADC supports 16/20/24-bit PCM format for independent two stereo channel audio inputs |
|
| Power Supply | 260W 90% | |
| Network & Wireless Connectivity | Wi-Fi 6, 802.11ax 2×2 + BT5.2 Ethernet: Integrated 100/1000M |
|
| Operating System | FreeDOS | |
| Security Management | Security Chip: Firmware TPM 2.0 integrated in SoC | |
| Input Devices | ||
| Keyboard | USB Calliope Keyboard, Black, English | |
| Mouse | USB Calliope Mouse, Black | |
| External I/O Ports | Front Ports: 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with 15W charging 2x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x headphone/microphone combo jack (3.5mm) 1x microphone (3.5mm) Rear Ports: 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), with Smart Power On 2x USB-A (Hi-Speed USB / USB 2.0) 1x HDMI 2.1 TMDS 1x VGA 1x Ethernet (RJ-45) 1x audio-out (3.5mm) 1x power connector |
|
| Physical Details | ||
| Dimension | 89 x 291.4 x 339.5mm (3.5 x 11.5 x 13.4 inches) | |
| Weight | Around 3.59 kg (7.9 lbs) | |
| Color | Cloud Grey | |
| Warranty Information | ||
| Warranty | 3 Years | |
